| VND5012AK-E | STMicroelectronics | Check for Price | Buffer/Inverter Based Peripheral Driver, 2 Driver, CMOS, PDSO24 | VND5012AKTR-E vs VND5012AK-E |
Part Details for VND5012AKTR-E by STMicroelectronics
Results Overview of VND5012AKTR-E by STMicroelectronics
- Distributor Offerings: (10 listings)
- Number of FFF Equivalents: (1 replacement)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (9 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
Transportation and Logistics
Renewable Energy
Automotive
VND5012AKTR-E Information
VND5012AKTR-E by STMicroelectronics is a Peripheral Driver.
Peripheral Drivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for VND5012AKTR-E
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
497-11690-6-ND
|
DigiKey | IC PWR DRVR N-CHAN 1:1 PWRSSO24 Min Qty: 1 Container: Digi-Reel |
1924 Digi-Reel® |
|
$4.2052 / $6.7100 | Buy Now |
|
DISTI #
497-11690-1-ND
|
DigiKey | IC PWR DRVR N-CHAN 1:1 PWRSSO24 Min Qty: 1 Container: Cut Tape |
1924 Cut Tape |
|
$4.2052 / $6.7100 | Buy Now |
|
DISTI #
497-11690-2-ND
|
DigiKey | IC PWR DRVR N-CHAN 1:1 PWRSSO24 Min Qty: 1000 Container: Tape & Reel |
1000 Tape & Reel |
|
$3.8393 / $3.9223 | Buy Now |
|
DISTI #
511-VND5012AKTR-E
|
Mouser Electronics | Power Switch ICs - Power Distribution Double Ch Hi Side Driver analog RoHS: Compliant | 1703 |
|
$3.9100 / $6.4400 | Buy Now |
|
|
STMicroelectronics | Double channel high side driver with analog current sense for automotive applications COO: Singapore Min Qty: 1 | 1703 |
|
$3.9200 / $6.4400 | Buy Now |
|
|
Bristol Electronics | Current Limit SW 2-IN 2-OUT to 84A Automotive AEC-Q100 24-Pin PowerSSO EP T/R Min Qty: 1 | 1942 |
|
$3.0392 / $7.0680 | Buy Now |
|
|
Quest Components | BUFFER/INVERTER BASED PERIPHERAL DRIVER, 2 DRIVER, CMOS, PDSO24 | 1553 |
|
$3.2550 / $9.3000 | Buy Now |
|
|
Quest Components | BUFFER/INVERTER BASED PERIPHERAL DRIVER, 2 DRIVER, CMOS, PDSO24 | 340 |
|
$3.5550 / $8.8875 | Buy Now |
|
DISTI #
VND5012AKTR-E
|
TME | IC: power switch, high-side, 60A, Ch: 2, SMD, PowerSSO24, reel,tape Min Qty: 1 | 818 |
|
$4.2700 / $6.0200 | Buy Now |
|
|
Chip Stock | Power Load Distribution Switch, Low Side, Active Low, 4 Outputs, 5.5V, 5A, 0.15ohm, SOIC-20 | 11500 |
|
RFQ |
US Tariff Estimator: VND5012AKTR-E by STMicroelectronics
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
VND5012AKTR-E CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
VND5012AKTR-E Part Data Attributes
|
|
VND5012AKTR-E
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
VND5012AKTR-E
STMicroelectronics
Buffer/Inverter Based Peripheral Driver, 2 Driver, CMOS, PDSO24
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Part Package Code | SOIC | |
| Package Description | Rohs Compliant, Power, Sso-24 | |
| Pin Count | 24 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.60 | |
| Factory Lead Time | 13 Weeks | |
| Built-in Protections | Transient; Over Current; Over Voltage; Thermal; Under Voltage | |
| Driver Number of Bits | 2 | |
| Interface IC Type | Buffer Or Inverter Based Peripheral Driver | |
| JESD-30 Code | R-PDSO-G24 | |
| JESD-609 Code | e3 | |
| Length | 10.3 Mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 2 | |
| Number of Terminals | 24 | |
| Output Current Flow Direction | Source | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | HSSOP | |
| Package Equivalence Code | SOP24,.4,32 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Heat Sink/Slug, Shrink Pitch | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2.47 Mm | |
| Supply Voltage-Max | 36 V | |
| Supply Voltage-Min | 4.5 V | |
| Supply Voltage-Nom | 13 V | |
| Surface Mount | Yes | |
| Technology | Cmos | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.8 Mm | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | Not Specified | |
| Width | 7.5 Mm |
Alternate Parts for VND5012AKTR-E
