0014562064 by: Molex

Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal, ROHS COMPLIANT

Part Details for 0014562064 by Molex

Results Overview of 0014562064 by Molex

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Computing and Data Storage Electronic Manufacturing

0014562064 Information

0014562064 by Molex is a Header and Edge Type Connector.
Headers and Edge Type Connectors are under the broader part category of Connectors.

Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.

Price & Stock for 0014562064

Part # Distributor Description Stock Price Buy
DISTI # WM20961-ND
DigiKey CONN RCPT 6POS IDC 26AWG GOLD Min Qty: 1 Lead time: 26 Weeks Container: Tube 106
In Stock
  • 1 $1.9700
  • 10 $1.6760
  • 25 $1.5704
  • 50 $1.4954
  • 100 $1.4239
  • 250 $1.3346
  • 500 $1.2709
  • 1,000 $1.2103
  • 2,500 $1.1345
$1.1345 / $1.9700 Buy Now
DISTI # 0014562064
Avnet Americas Conn IDC Connector F 6 POS 2.54mm IDT ST Cable Mount Tube - Rail/Tube (Alt: 0014562064) COO: United States of America (the) RoHS: Compliant Min Qty: 2100 Package Multiple: 1050 Lead time: 24 Weeks, 0 Days Container: Tube 0
  • 2,100 $1.1204
  • 8,400 $0.9569
  • 21,000 $0.9215
  • 40,950 $0.9167
  • 100,800 $0.9120
$0.9120 / $1.1204 Buy Now
DISTI # MOL14-56-2064
Heilind Electronics CGRID SL IDT OPT G 15 SAU 6CKT Americas - 0 in Stock
  • 2,100 $1.1501
  • 6,300 $1.1041
$1.1041 / $1.1501 Buy Now

US Tariff Estimator: 0014562064 by Molex

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

0014562064
Molex
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for 0014562064

0014562064 Part Data Attributes

Parametric Data
0014562064 Molex
Buy Now Datasheet
Compare Parts:
0014562064 Molex Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal, ROHS COMPLIANT
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Package Description Rohs Compliant
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8536.69.40.40
Additional Feature Polarized
Body Depth 0.6 Inch
Body Length 0.599 Inch
Connector Type Board Connector
Contact Finish Mating Not Specified
Contact Finish Termination Tin (Sn)
Contact Gender Female
Contact Material Phosphor Bronze
Contact Pattern Rectangular
Contact Style Sq Pin-Skt
DIN Conformance No
Filter Feature No
IEC Conformance No
JESD-609 Code e3
MIL Conformance No
Mating Contact Pitch 0.1 Inch
Mating Information Multiple Mating Parts Available
Mixed Contacts No
Mounting Option 1 Locking
Mounting Type Cable
Number Of Connectors One
Number of Rows Loaded 1
Operating Temperature-Max 105 °C
Operating Temperature-Min -40 °C
Option General Purpose
Rated Current (Signal) 3 A
Termination Type Idc
Total Number of Contacts 6
UL Flammability Code 94V-0

Alternate Parts for 0014562064

This table gives cross-reference parts and alternative options found for 0014562064. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 0014562064, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
A-7674-B6A154A Molex Check for Price Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal 0014562064 vs A-7674-B6A154A
0009061069 Molex Check for Price Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal, ROHS COMPLIANT 0014562064 vs 0009061069
26-35-2061 Molex Check for Price Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal 0014562064 vs 26-35-2061
0009071069 Molex Check for Price Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal, ROHS COMPLIANT 0014562064 vs 0009071069
A-7674-B6J561A Molex Check for Price Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal 0014562064 vs A-7674-B6J561A
A-7674-B6D102A Molex Check for Price Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal 0014562064 vs A-7674-B6D102A
A-7674-C6D154A Molex Check for Price Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal 0014562064 vs A-7674-C6D154A
827773-6 TE's AMP Check for Price 6 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, IDC 0014562064 vs 827773-6
3-641301-6 TE Connectivity Check for Price CONNECTOR, 6 CONTACT(S), FEMALE, TWO PART BOARD CONNECTOR, IDC 0014562064 vs 3-641301-6
38-00-3286 Molex Check for Price Board Connector, 6 Contact(s), 1 Row(s), Female, IDC Terminal 0014562064 vs 38-00-3286
equivalents icon

0014562064 Frequently Asked Questions (FAQ)

  • The recommended torque for the screw terminals is 0.5-1.5 Nm (4.4-13.3 in-lbs).

  • Yes, the contacts are gold-plated to ensure reliable connections and prevent corrosion.

  • The operating temperature range for the 0014562064 connector is -40°C to 105°C (-40°F to 221°F).

  • Yes, the 0014562064 connector is designed to withstand high-vibration environments, making it suitable for applications such as industrial control systems, automotive, and aerospace.

  • Yes, the 0014562064 connector is suitable for signal transmission applications, including audio, video, and data transmission.
