Capacitors / Fixed Capacitors / 293D225X9010A2WE3
Datasheets
293D225X9010A2WE3 by:
Vishay Intertechnologies

Tantalum Capacitor, Polarized, Tantalum (dry/solid), 10V, 10% +Tol, 10% -Tol, 2.2uF, Surface Mount, 1206, CHIP

Part Details for 293D225X9010A2WE3 by Vishay Intertechnologies

Results Overview of 293D225X9010A2WE3 by Vishay Intertechnologies

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Energy and Power Systems

293D225X9010A2WE3 Information

293D225X9010A2WE3 by Vishay Intertechnologies is a Fixed Capacitor.
Fixed Capacitors are under the broader part category of Capacitors.

A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.

Price & Stock for 293D225X9010A2WE3

Part # Distributor Description Stock Price Buy
DISTI # 66AJ2010
Newark Cap, 2.2Uf, 10V, Tant, Case A, Capacitance:2.2Μf, Voltage(Dc):10V, Capacitor Case/Package:1206 [3216 Metric], Capacitance Tolerance:± 10%, Esr:6.3Ohm, Manufacturer Size Code:A, Failure Rate:-, Ripple Current:110Ma, Qualification:- Rohs Compliant: Yes |Vishay 293D225X9010A2WE3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 7279
  • 1 $0.0870
  • 25 $0.0870
  • 100 $0.0870
  • 250 $0.0870
  • 500 $0.0870
  • 1,000 $0.0870
  • 2,500 $0.0870
$0.0870 Buy Now
DISTI # 09K6165
Newark Cap, 2.2Uf, 10V, Tant, Case A, Capacitance:2.2Μf, Voltage(Dc):10V, Capacitor Case/Package:1206 [3216 Metric], Capacitance Tolerance:± 10%, Esr:6.3Ohm, Manufacturer Size Code:A, Failure Rate:-, Ripple Current:110Ma, Qualification:- Rohs Compliant: Yes |Vishay 293D225X9010A2WE3 RoHS: Compliant Min Qty: 9000 Package Multiple: 1 Date Code: 0 Container: Tape & Reel 0
  • 5,000 $0.1780
  • 10,000 $0.1590
  • 20,000 $0.1440
  • 30,000 $0.1350
  • 50,000 $0.1240
$0.1240 / $0.1780 Buy Now
DISTI # 66AJ2010
Avnet Americas - Product that comes on tape, but is not reeled (Alt: 66AJ2010) COO: China RoHS: Compliant Min Qty: 1 Package Multiple: 1 Container: Ammo Pack 7279 Partner Stock
  • 1 $0.5390
  • 25 $0.4740
  • 100 $0.4160
  • 250 $0.3460
  • 500 $0.2900
  • 1,000 $0.2440
  • 2,500 $0.2010
$0.2010 / $0.5390 Buy Now
DISTI # 293D225X9010A2WE3
Avnet Americas - Tape and Reel (Alt: 293D225X9010A2WE3) COO: China RoHS: Compliant Min Qty: 9000 Package Multiple: 9000 Lead time: 13 Weeks, 0 Days Container: Tape & Reel 0
  • 9,000 $0.0844
  • 18,000 $0.0839
  • 36,000 $0.0835
  • 72,000 $0.0831
  • 144,000 $0.0827
$0.0827 / $0.0844 Buy Now
DISTI # 71-293D225X9010A2WE3
Mouser Electronics Tantalum Capacitors - Solid SMD 293D225X9010A2We3 RoHS: Compliant 0
  • 9,000 $0.0940
  • 27,000 $0.0850
$0.0850 / $0.0940 Order Now
Future Electronics 293D Series 2.2 uF ±10 % 10V Surface Mount Standard Molded Tantalum Capacitor RoHS: Compliant pbFree: Yes Min Qty: 9000 Package Multiple: 9000 Lead time: 13 Weeks Container: Reel 0
Reel
  • 9,000 $0.0518
  • 18,000 $0.0509
  • 27,000 $0.0504
  • 36,000 $0.0498
$0.0498 / $0.0518 Buy Now
DISTI # 86237062
Verical Cap Tant Solid 2.2uF 10V A CASE 10% (3.2 X 1.6 X 1.6mm) Inward L SMD 3216-18 6.3 Ohm 125°C T/R RoHS: Compliant Min Qty: 575 Package Multiple: 1 Americas - 7279
  • 575 $0.1314
  • 1,000 $0.1272
  • 2,500 $0.1234
  • 5,000 $0.1201
$0.1201 / $0.1314 Buy Now
DISTI # 86237062
Verical Cap Tant Solid 2.2uF 10V A CASE 10% (3.2 X 1.6 X 1.6mm) Inward L SMD 3216-18 6.3 Ohm 125°C T/R COO: China RoHS: Compliant Min Qty: 575 Package Multiple: 1 Americas - 7279
  • 575 $0.1314
  • 1,000 $0.1272
  • 2,500 $0.1234
  • 5,000 $0.1201
$0.1201 / $0.1314 Buy Now
DISTI # 86237062
Verical Cap Tant Solid 2.2uF 10V A CASE 10% (3.2 X 1.6 X 1.6mm) Inward L SMD 3216-18 6.3 Ohm 125°C T/R COO: China RoHS: Compliant Min Qty: 575 Package Multiple: 1 Americas - 7279
  • 575 $0.1314
  • 1,000 $0.1272
  • 2,500 $0.1234
  • 5,000 $0.1201
$0.1201 / $0.1314 Buy Now
DISTI # 293D225X9010A2WE3
Avnet Abacus - Tape and Reel (Alt: 293D225X9010A2WE3) RoHS: Compliant Min Qty: 9000 Package Multiple: 9000 Lead time: 16 Weeks, 0 Days Container: Tape & Reel Abacus - 0
Buy Now

US Tariff Estimator: 293D225X9010A2WE3 by Vishay Intertechnologies

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

293D225X9010A2WE3
Vishay Intertechnologies
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for 293D225X9010A2WE3

293D225X9010A2WE3 CAD Models

  • Part Symbol

    schematic symbol

  • Footprint

    pcb footprint

  • 3D Model

    2d presentation

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

293D225X9010A2WE3 Part Data Attributes

Parametric Data
293D225X9010A2WE3 Vishay Intertechnologies
Buy Now Datasheet
Compare Parts:
293D225X9010A2WE3 Vishay Intertechnologies Tantalum Capacitor, Polarized, Tantalum (dry/solid), 10V, 10% +Tol, 10% -Tol, 2.2uF, Surface Mount, 1206, CHIP
Rohs Code Yes
Part Life Cycle Code Active
Package Description Chip
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8532.21.00.50
Additional Feature Esr And Ripple Current Is Measured At 100khz
Capacitance 2.2 µF
Capacitor Type Tantalum Capacitor
Dielectric Material Tantalum (Dry/Solid)
ESR 6300 MΩ
Height 1.6 Mm
JESD-609 Code e3
Leakage Current 0.0005 Ma
Length 3.2 Mm
Mounting Feature Surface Mount
Negative Tolerance 10%
Number of Terminals 2
Operating Temperature-Max 125 °C
Operating Temperature-Min -55 °C
Package Shape Rectangular Package
Package Style Smt
Packing Method Tr, Embossed Plastic, 13 Inch
Polarity Polarized
Positive Tolerance 10%
Rated (DC) Voltage (URdc) 10 V
Ripple Current 110 Ma
Size Code 1206
Surface Mount Yes
Tan Delta 0.06
Terminal Finish Matte Tin (Sn) - With Nickel (Ni) Barrier
Terminal Shape J Bend
Width 1.6 Mm

Alternate Parts for 293D225X9010A2WE3

This table gives cross-reference parts and alternative options found for 293D225X9010A2WE3. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of 293D225X9010A2WE3, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
CWR11FB225KTBULK Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs CWR11FB225KTBULK
TBJA225K010CLLCT723 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs TBJA225K010CLLCT723
TBJA225K010CBLZT924 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs TBJA225K010CBLZT924
TBJA225K010CKSCT000 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs TBJA225K010CKSCT000
TBJA225K010CGLD0800 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs TBJA225K010CGLD0800
TBJA225K010CKLCTH23 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs TBJA225K010CKLCTH23
TBJA225K010CWMD0724 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs TBJA225K010CWMD0724
TBJA225K010CSMZT924 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs TBJA225K010CSMZT924
TBJA225K010CELD0H24 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs TBJA225K010CELD0H24
TBJA225K010CAMZ0900 Kyocera AVX Components Check for Price Tantalum Capacitor, Polarized, Tantalum, 10V, 10% +Tol, 10% -Tol, 2.2uF, 1206, 293D225X9010A2WE3 vs TBJA225K010CAMZ0900
equivalents icon

293D225X9010A2WE3 Related Parts

293D225X9010A2WE3 Frequently Asked Questions (FAQ)

  • The recommended soldering temperature for the 293D225X9010A2WE3 capacitor is between 260°C to 280°C for a maximum of 10 seconds.

  • Yes, the 293D225X9010A2WE3 capacitor is designed for high-reliability applications and meets the requirements of MIL-PRF-123 and IEC 60384-16 standards.

  • The ESR of the 293D225X9010A2WE3 capacitor is typically around 0.015 ohms at 100 kHz and 25°C.

  • Yes, the 293D225X9010A2WE3 capacitor is designed to withstand high-vibration environments and meets the requirements of IEC 60068-2-6 standard.

  • The shelf life of the 293D225X9010A2WE3 capacitor is typically 2 years from the date of manufacture, as long as it is stored in its original packaging and under recommended storage conditions.
