Part Details for CDC318ADL by Texas Instruments
Results Overview of CDC318ADL by Texas Instruments
- Distributor Offerings: (14 listings)
- Number of FFF Equivalents: (10 replacements)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (10 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
CDC318ADL Information
CDC318ADL by Texas Instruments is a Clock Driver.
Clock Drivers are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| CDC318ADLG4 | Texas Instruments | 1-Line To 18-Line Clock Driver With I<sup>2</sup>C Control Interface 48-SSOP 0 to 70 | |
| CDC318ADLR | Texas Instruments | 1-Line To 18-Line Clock Driver With I<sup>2</sup>C Control Interface 48-SSOP 0 to 70 | |
| CDC318ADLRG4 | Texas Instruments | 1-Line To 18-Line Clock Driver With I<sup>2</sup>C Control Interface 48-SSOP 0 to 70 |
Price & Stock for CDC318ADL
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
85975210
|
Verical | Clock Driver 18-OUT 1-IN 1:18 48-Pin SSOP Tube RoHS: Compliant Min Qty: 34 Package Multiple: 1 Date Code: 1001 | Americas - 3415 |
|
$8.9000 / $11.1250 | Buy Now |
|
DISTI #
85970583
|
Verical | Clock Driver 18-OUT 1-IN 1:18 48-Pin SSOP Tube RoHS: Compliant Min Qty: 34 Package Multiple: 1 Date Code: 0601 | Americas - 775 |
|
$8.9000 / $11.1250 | Buy Now |
|
DISTI #
85978951
|
Verical | Clock Driver 18-OUT 1-IN 1:18 48-Pin SSOP Tube RoHS: Compliant Min Qty: 34 Package Multiple: 1 Date Code: 1501 | Americas - 75 |
|
$8.9000 / $11.1250 | Buy Now |
|
DISTI #
595-CDC318ADL
|
Mouser Electronics | Clock Drivers & Distribution 1Line18Line Clk Drvr A 595-CDC318ADLR A A 595-CDC318ADLR RoHS: Compliant | 0 |
|
$10.9400 / $15.8900 | Order Now |
|
|
Bristol Electronics | Clock Driver 18-OUT 1-IN 1:18 48-Pin SSOP Tube | 1337 |
|
RFQ | |
|
|
Quest Components | LOW SKEW CLOCK DRIVER, 318 SERIES, 18 TRUE OUTPUT(S), 0 INVERTED OUTPUT(S), BICMOS, PDSO48 | 829 |
|
$3.2550 / $9.3000 | Buy Now |
|
|
Quest Components | LOW SKEW CLOCK DRIVER, 318 SERIES, 18 TRUE OUTPUT(S), 0 INVERTED OUTPUT(S), BICMOS, PDSO48 | 48 |
|
$4.0300 / $9.3000 | Buy Now |
|
|
Rochester Electronics | Clock Buffer 1:18 100MHz 48-SOP Tube RoHS: Compliant Status: Active Min Qty: 1 | 4289 |
|
$7.1200 / $8.9000 | Buy Now |
|
DISTI #
85975210
|
Verical | Clock Driver 18-OUT 1-IN 1:18 48-Pin SSOP Tube RoHS: Compliant Min Qty: 34 Package Multiple: 1 Date Code: 1001 | Americas - 3415 |
|
$8.9000 / $11.1250 | Buy Now |
|
DISTI #
85970583
|
Verical | Clock Driver 18-OUT 1-IN 1:18 48-Pin SSOP Tube RoHS: Compliant Min Qty: 34 Package Multiple: 1 Date Code: 0601 | Americas - 775 |
|
$8.9000 / $11.1250 | Buy Now |
US Tariff Estimator: CDC318ADL by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
CDC318ADL CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
CDC318ADL Part Data Attributes
|
|
CDC318ADL
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
CDC318ADL
Texas Instruments
Low Skew Clock Driver, 318 Series, 18 True Output(s), 0 Inverted Output(s), BICMOS, PDSO48
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Part Package Code | SSOP | |
| Package Description | Ssop-48 | |
| Pin Count | 48 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.90 | |
| Family | 318 | |
| Input Conditioning | Standard | |
| JESD-30 Code | R-PDSO-G48 | |
| JESD-609 Code | e4 | |
| Length | 15.875 Mm | |
| Logic IC Type | Low Skew Clock Driver | |
| Max I(ol) | 0.024 A | |
| Moisture Sensitivity Level | 2 | |
| Number of Functions | 1 | |
| Number of Inverted Outputs | ||
| Number of Terminals | 48 | |
| Number of True Outputs | 18 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Output Characteristics | 3-State | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | SSOP | |
| Package Equivalence Code | SSOP48,.4 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Shrink Pitch | |
| Packing Method | Tube | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power Supply Current-Max (ICC) | 0.5 Ma | |
| Prop. Delay@Nom-Sup | 4.5 Ns | |
| Propagation Delay (tpd) | 4.5 Ns | |
| Qualification Status | Not Qualified | |
| Same Edge Skew-Max (tskwd) | 0.25 Ns | |
| Seated Height-Max | 2.79 Mm | |
| Supply Voltage-Max (Vsup) | 3.465 V | |
| Supply Voltage-Min (Vsup) | 3.135 V | |
| Supply Voltage-Nom (Vsup) | 3.3 V | |
| Surface Mount | Yes | |
| Technology | Bicmos | |
| Temperature Grade | Commercial | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.635 Mm | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 7.49 Mm | |
| fmax-Min | 100 Mhz |
