Resistors / Fixed Resistors / CSS2010FT1L00
Datasheets
CSS2010FT1L00 by: SEI Stackpole Electronics Inc

Fixed Resistor, Metal Strip, 1W, 0.001ohm, 0.032V, 1% +/-Tol, 50ppm/Cel, Surface Mount, 2010

Part Details for CSS2010FT1L00 by SEI Stackpole Electronics Inc

Results Overview of CSS2010FT1L00 by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Security and Surveillance Environmental Monitoring Internet of Things (IoT) Space Technology Smart Cities Aerospace and Defense Healthcare Agriculture Technology Virtual Reality (VR), Augmented Reality (AR), and Vision Systems Medical Imaging Robotics and Drones

CSS2010FT1L00 Information

CSS2010FT1L00 by SEI Stackpole Electronics Inc is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for CSS2010FT1L00

Part # Distributor Description Stock Price Buy
DISTI # CSS2010FT1L00-ND
DigiKey RES 0.001 OHM 1% 1W 2010 Min Qty: 4000 Lead time: 17 Weeks Container: Tape & Reel (TR) Temporarily Out of Stock
  • 4,000 $0.2838
$0.2838 Buy Now
DISTI # CSS2010FT1L00
Avnet Americas - Tape and Reel (Alt: CSS2010FT1L00) COO: Taiwan (Province of China) RoHS: Compliant Min Qty: 4000 Package Multiple: 2000 Lead time: 17 Weeks, 0 Days Container: Tape & Reel 2000 Factory Stock
  • 4,000 $0.2714
  • 8,000 $0.2568
  • 12,000 $0.2500
  • 20,000 $0.2436
  • 40,000 $0.2375
$0.2375 / $0.2714 Buy Now
DISTI # 708-CSS2010FT1L00
Mouser Electronics Current Sense Resistors - SMD RES SHUNT, 2010, 0.001 ohm, 1%, 1W RoHS: Compliant 0
  • 2,000 $0.2830
  • 4,000 $0.2830
$0.2830 Order Now
DISTI # V36:1790_06923772
Arrow Electronics Res Metal Alloy 2010 0.001 Ohm 1% 1W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 COO: Taiwan RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 15 Weeks Date Code: 2319 Americas - 2000
  • 0 $0.2276
  • 2,000 $0.0554
$0.0554 / $0.2276 Buy Now
Onlinecomponents.com Ultra-Precision Metal Alloy Current Sense Resistor - 0.001 ohm ±1% - 1W - 2010 - Tape&Reel COO: Taiwan RoHS: Compliant 2000 Factory Stock
  • 1,000 $0.3800
  • 2,000 $0.2850
  • 3,000 $0.2660
  • 4,000 $0.2607
$0.2607 / $0.3800 Buy Now
DISTI # 54069914
Verical Res Metal Alloy 2010 0.001 Ohm 1% 1W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 106 Package Multiple: 1 Americas - 2000
  • 106 $0.7756
  • 250 $0.7445
  • 500 $0.7177
  • 1,000 $0.6943
$0.6943 / $0.7756 Buy Now
DISTI # 69806982
Verical Res Metal Alloy 2010 0.001 Ohm 1% 1W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Date Code: 2319 Americas - 2000
  • 2,000 $0.0554
$0.0554 Buy Now
DISTI # V36:1790_06923772
Arrow Electronics Res Metal Alloy 2010 0.001 Ohm 1% 1W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 COO: Taiwan RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 15 Weeks Date Code: 2319 Americas - 2000
  • 0 $0.2276
  • 2,000 $0.0554
$0.0554 / $0.2276 Buy Now
DISTI # 54069914
Verical Res Metal Alloy 2010 0.001 Ohm 1% 1W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 COO: Taiwan RoHS: Compliant Min Qty: 106 Package Multiple: 1 Americas - 2000
  • 106 $0.7756
  • 250 $0.7445
  • 500 $0.7177
  • 1,000 $0.6943
$0.6943 / $0.7756 Buy Now
DISTI # 69806982
Verical Res Metal Alloy 2010 0.001 Ohm 1% 1W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 COO: Taiwan RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Date Code: 2319 Americas - 2000
  • 2,000 $0.0554
$0.0554 Buy Now
DISTI # V36:1790_06923772
Arrow Electronics Res Metal Alloy 2010 0.001 Ohm 1% 1W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 COO: Taiwan RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 15 Weeks Date Code: 2319 Americas - 2000
  • 0 $0.2276
  • 2,000 $0.0554
$0.0554 / $0.2276 Buy Now
NAC RESISTOR SHUNT, 2010, 0.001 ohm, 1%, 1W - Ultra Stable Current Sense Metal Strip RoHS: Compliant Min Qty: 1 Package Multiple: 1 2000
  • 4,000 $0.4750
  • 20,000 $0.3170
  • 100,000 $0.2720
$0.2720 / $0.4750 Buy Now
DISTI # 54069914
Verical Res Metal Alloy 2010 0.001 Ohm 1% 1W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 COO: Taiwan RoHS: Compliant Min Qty: 106 Package Multiple: 1 Americas - 2000
  • 106 $0.7756
  • 250 $0.7445
  • 500 $0.7177
  • 1,000 $0.6943
$0.6943 / $0.7756 Buy Now
DISTI # 69806982
Verical Res Metal Alloy 2010 0.001 Ohm 1% 1W ±50ppm/°C Pad SMD T/R Automotive AEC-Q200 COO: Taiwan RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Date Code: 2319 Americas - 2000
  • 2,000 $0.0554
$0.0554 Buy Now
Master Electronics Ultra-Precision Metal Alloy Current Sense Resistor - 0.001 ohm ±1% - 1W - 2010 - Tape&Reel COO: Taiwan RoHS: Compliant 2000 Factory Stock
  • 1,000 $0.3800
  • 2,000 $0.2850
  • 3,000 $0.2660
  • 4,000 $0.2607
$0.2607 / $0.3800 Buy Now

US Tariff Estimator: CSS2010FT1L00 by SEI Stackpole Electronics Inc

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

CSS2010FT1L00
SEI Stackpole Electronics Inc
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for CSS2010FT1L00

CSS2010FT1L00 Part Data Attributes

Parametric Data
CSS2010FT1L00 SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
CSS2010FT1L00 SEI Stackpole Electronics Inc Fixed Resistor, Metal Strip, 1W, 0.001ohm, 0.032V, 1% +/-Tol, 50ppm/Cel, Surface Mount, 2010
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Package Description Chip
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8533.21.00.30
Factory Lead Time 17 Weeks
Additional Feature Ultra Precision
Construction Rectangular
JESD-609 Code e3
Mounting Feature Surface Mount
Number of Terminals 2
Operating Temperature-Max 225 °C
Operating Temperature-Min -55 °C
Package Height 0.79 Mm
Package Length 5.08 Mm
Package Style Smt
Package Width 2.54 Mm
Packing Method Tr, Embossed Plastic, 7 Inch
Rated Power Dissipation (P) 1 W
Rated Temperature 100 °C
Reference Standard Aec-Q200
Resistance 0.001 Ω
Resistor Type Fixed Resistor
Size Code 2010
Surface Mount Yes
Technology Metal Strip
Temperature Coefficient 50 Ppm/°C
Terminal Finish Matte Tin Over Nickel
Terminal Shape Wraparound
Tolerance 1%
Working Voltage 0.032 V
