Part Details for CY74FCT162373ATPVC by Texas Instruments
Results Overview of CY74FCT162373ATPVC by Texas Instruments
- Distributor Offerings: (12 listings)
- Number of FFF Equivalents: (10 replacements)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (10 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
CY74FCT162373ATPVC Information
CY74FCT162373ATPVC by Texas Instruments is a Bus Driver/Transceiver.
Bus Driver/Transceivers are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Price & Stock for CY74FCT162373ATPVC
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
86277790
|
Verical | Latch Transparent 3-ST 16-CH D-Type 48-Pin SSOP Tube RoHS: Compliant Min Qty: 228 Package Multiple: 1 Date Code: 1401 | Americas - 6585 |
|
$1.3875 / $1.6500 | Buy Now |
|
DISTI #
86277900
|
Verical | Latch Transparent 3-ST 16-CH D-Type 48-Pin SSOP Tube RoHS: Compliant Min Qty: 228 Package Multiple: 1 Date Code: 0401 | Americas - 5175 |
|
$1.3875 / $1.6500 | Buy Now |
|
DISTI #
86277774
|
Verical | Latch Transparent 3-ST 16-CH D-Type 48-Pin SSOP Tube RoHS: Compliant Min Qty: 228 Package Multiple: 1 Date Code: 1101 | Americas - 5025 |
|
$1.3875 / $1.6500 | Buy Now |
|
DISTI #
86277874
|
Verical | Latch Transparent 3-ST 16-CH D-Type 48-Pin SSOP Tube RoHS: Compliant Min Qty: 228 Package Multiple: 1 Date Code: 9901 | Americas - 2896 |
|
$1.3875 / $1.6500 | Buy Now |
|
DISTI #
86277956
|
Verical | Latch Transparent 3-ST 16-CH D-Type 48-Pin SSOP Tube RoHS: Compliant Min Qty: 228 Package Multiple: 1 Date Code: 0501 | Americas - 675 |
|
$1.3875 / $1.6500 | Buy Now |
|
DISTI #
86278401
|
Verical | Latch Transparent 3-ST 16-CH D-Type 48-Pin SSOP Tube RoHS: Compliant Min Qty: 228 Package Multiple: 1 Date Code: 0701 | Americas - 400 |
|
$1.3875 / $1.6500 | Buy Now |
|
DISTI #
86278519
|
Verical | Latch Transparent 3-ST 16-CH D-Type 48-Pin SSOP Tube RoHS: Compliant Min Qty: 228 Package Multiple: 1 | Americas - 393 |
|
$1.3875 / $1.6500 | Buy Now |
|
DISTI #
86277683
|
Verical | Latch Transparent 3-ST 16-CH D-Type 48-Pin SSOP Tube RoHS: Compliant Min Qty: 228 Package Multiple: 1 Date Code: 0601 | Americas - 259 |
|
$1.3875 / $1.6500 | Buy Now |
|
|
Bristol Electronics | Latch Transparent 3-ST 16-CH D-Type 48-Pin SSOP Tube Min Qty: 1 | 175 |
|
$1.1902 / $2.6448 | Buy Now |
|
|
Quest Components | FCT SERIES, DUAL 8-BIT DRIVER, TRUE OUTPUT, PDSO48 | 140 |
|
$1.7200 / $3.4400 | Buy Now |
US Tariff Estimator: CY74FCT162373ATPVC by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
CY74FCT162373ATPVC CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
CY74FCT162373ATPVC Part Data Attributes
|
|
CY74FCT162373ATPVC
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
CY74FCT162373ATPVC
Texas Instruments
Bus Driver, FCT Series, 16-Func, 8-Bit, True Output, CMOS, PDSO48
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Part Package Code | SSOP | |
| Package Description | Ssop-48 | |
| Pin Count | 48 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Control Type | Enable Low/High | |
| Count Direction | Unidirectional | |
| Family | Fct | |
| JESD-30 Code | R-PDSO-G48 | |
| JESD-609 Code | e4 | |
| Length | 15.875 Mm | |
| Load Capacitance (CL) | 50 Pf | |
| Logic IC Type | Bus Driver | |
| Max I(ol) | 0.024 A | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 8 | |
| Number of Functions | 16 | |
| Number of Ports | 2 | |
| Number of Terminals | 48 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Characteristics | 3-State With Series Resistor | |
| Output Polarity | True | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | SSOP | |
| Package Equivalence Code | SSOP48,.4 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Shrink Pitch | |
| Packing Method | Tube | |
| Peak Reflow Temperature (Cel) | 260 | |
| Power Supply Current-Max (ICC) | 0.5 Ma | |
| Prop. Delay@Nom-Sup | 5.2 Ns | |
| Propagation Delay (tpd) | 6.7 Ns | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2.79 Mm | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 4.5 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | Yes | |
| Technology | Cmos | |
| Temperature Grade | Industrial | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.635 Mm | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 7.49 Mm |
