| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| DP8570AVX | National Semiconductor Corporation | Check for Price | Real Time Clock, Volatile, 2 Timer(s), CMOS, PQCC28 | DP8570AV vs DP8570AVX |
| DP8570AV/NOPB | National Semiconductor Corporation | Check for Price | Real Time Clock, Volatile, 2 Timer(s), CMOS, PQCC28 | DP8570AV vs DP8570AV/NOPB |
| DP8570AV | National Semiconductor Corporation | Check for Price | Real Time Clock, Volatile, 2 Timer(s), CMOS, PQCC28 | DP8570AV vs DP8570AV |
Part Details for DP8570AV by Texas Instruments
Results Overview of DP8570AV by Texas Instruments
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (3 replacements)
- Tariff Estimator: (Available) NEW
- Number of Functional Equivalents: (4 options)
- CAD Models: (Available)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Industrial Automation
Renewable Energy
Robotics and Drones
DP8570AV Information
DP8570AV by Texas Instruments is a Timer or RTC.
Timers or RTCs are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Price & Stock for DP8570AV
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
DP8570AV-ND
|
DigiKey | IC RTC TIMER PERIPH PAR 28PLCC Container: Tube |
0 Tube |
|
Buy Now | |
|
DISTI #
85984711
|
Verical | Real Time Clock Parallel 32byte Clock/Calendar/Alarm/Battery Backup/Interrupt 28-Pin PLCC Tube RoHS: Not Compliant Min Qty: 25 Package Multiple: 1 Date Code: 1501 | Americas - 550 |
|
$24.3000 / $30.3750 | Buy Now |
|
DISTI #
85985287
|
Verical | Real Time Clock Parallel 32byte Clock/Calendar/Alarm/Battery Backup/Interrupt 28-Pin PLCC Tube RoHS: Not Compliant Min Qty: 25 Package Multiple: 1 Date Code: 1301 | Americas - 28 |
|
$24.3000 / $30.3750 | Buy Now |
|
|
Quest Components | IC,REAL-TIME CLOCK,CMOS,LDCC,28PIN,PLASTIC | 16 |
|
$57.6720 / $64.0800 | Buy Now |
|
|
Rochester Electronics | Real Time Clock, Volatile, 2 Timer(s), CMOS, PQCC28 RoHS: Not Compliant Status: Obsolete Min Qty: 1 | 578 |
|
$19.4400 / $24.3000 | Buy Now |
|
|
Chip Stock | Real Time Clock Parallel 32byte Clock/Calendar/Alarm/Battery Backup/Interrupt 28-Pin PLCC Tube | 2718 |
|
RFQ |
US Tariff Estimator: DP8570AV by Texas Instruments
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
DP8570AV CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
DP8570AV Part Data Attributes
|
|
DP8570AV
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
DP8570AV
Texas Instruments
Real Time Clock, Volatile, 2 Timer(s), CMOS, PQCC28
|
| Part Life Cycle Code | Obsolete | |
| Part Package Code | QLCC | |
| Package Description | Plastic, Lcc-28 | |
| Pin Count | 28 | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.60 | |
| Additional Feature | 4 Programmable Modes For Timer; 4 Selectable Oscillator Frequencies | |
| Clock Frequency-Max | 10 Mhz | |
| External Data Bus Width | 8 | |
| Information Access Method | Parallel, Direct Address | |
| Interrupt Capability | Y | |
| JESD-30 Code | S-PQCC-J28 | |
| JESD-609 Code | e0 | |
| Length | 11.43 Mm | |
| Moisture Sensitivity Level | 2a | |
| Number of Bits | 16 | |
| Number of Terminals | 28 | |
| Number of Timers | 2 | |
| On Chip Data RAM Width | 8 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | QCCJ | |
| Package Equivalence Code | LDCC28,.5SQ | |
| Package Shape | Square | |
| Package Style | Chip Carrier | |
| Peak Reflow Temperature (Cel) | 245 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 4.57 Mm | |
| Supply Current-Max | 20 Ma | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 4.5 V | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | Yes | |
| Technology | Cmos | |
| Temperature Grade | Industrial | |
| Terminal Finish | Tin Lead | |
| Terminal Form | J Bend | |
| Terminal Pitch | 1.27 Mm | |
| Terminal Position | Quad | |
| Time-Min | 1/100 Second | |
| Volatile | Yes | |
| Width | 11.43 Mm | |
| uPs/uCs/Peripheral ICs Type | Timer, Real Time Clock |
