LDK320AM-R Information
LDK320AM-R by STMicroelectronics is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LDK320AM-R
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
07AH6603
|
Newark | Ldo, Adj, 12V, 0.2A, -40 To 125Deg C, Output Type:Adjustable, Input Voltage Min:2.5V, Input Voltage Max:18V, Fixed Output Voltage Nom.:-, Adjustable Output Voltage Min:1.2V, Adjustable Output Voltage Max:12V, Output Current:200Ma, Rohs Compliant: Yes RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 12387 |
|
$0.2060 / $0.4020 | Buy Now |
|
DISTI #
497-16672-1-ND
|
DigiKey | IC REG LIN POS ADJ 200MA SOT23-5 Min Qty: 1 Lead time: 24 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) |
4559 In Stock |
|
$0.1600 / $0.4100 | Buy Now |
|
DISTI #
LDK320AM-R
|
Avnet Americas | LDO Regulator Positive 0.2A 5-Pin SOT-23 T/R - Tape and Reel (Alt: LDK320AM-R) COO: Italy RoHS: Compliant Min Qty: 6000 Package Multiple: 3000 Lead time: 24 Weeks, 0 Days Container: Tape & Reel | 0 |
|
$0.1380 / $0.1467 | Buy Now |
|
DISTI #
511-LDK320AM-R
|
Mouser Electronics | LDO Voltage Regulators 200 mA low quiescent current and high PSRR voltage regulator RoHS: Compliant | 56992 |
|
$0.1910 / $0.4100 | Buy Now |
|
|
STMicroelectronics | 200 mA low quiescent current and high PSRR voltage regulator COO: Italy RoHS: Compliant Min Qty: 1 | 56992 |
|
$0.1900 / $0.4100 | Buy Now |
|
|
Future Electronics | LDK320 Series 200 mA ADJ Output SMT Low Drop Voltage Regulator - SOT-23-5 RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 24 Weeks Container: Reel | 0Reel |
|
$0.1360 / $0.1420 | Buy Now |
|
DISTI #
93261618
|
Verical | LDO Regulator Pos 1.2V to 12V 0.2A 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 6 Package Multiple: 1 | Americas - 2850 |
|
$0.3248 | Buy Now |
|
DISTI #
93135770
|
Verical | LDO Regulator Pos 1.2V to 12V 0.2A 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 42 Package Multiple: 1 Date Code: 2541 | Americas - 1528 |
|
$0.1627 / $0.2463 | Buy Now |
|
|
Rochester Electronics | LDK320 - Power Management-LINEAR VOLTAGE RoHS: Compliant Status: Active Min Qty: 1 | 2874 |
|
$0.1525 / $0.2460 | Buy Now |
|
DISTI #
LDK320AM-R
|
TME | IC: voltage regulator, LDO,linear,adjustable, 1.2÷12V, 0.2A, SMD Min Qty: 1 | 2276 |
|
$0.1720 / $0.3600 | Buy Now |
US Tariff Estimator: LDK320AM-R by STMicroelectronics
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
Part Details for LDK320AM-R
LDK320AM-R CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
LDK320AM-R Part Data Attributes
|
|
LDK320AM-R
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
LDK320AM-R
STMicroelectronics
Adjustable Positive LDO Regulator, 1.182V Min, 1.218V Max, 0.35V Dropout, PDSO5
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Package Description | Sot-23, 5 Pin | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.60 | |
| Factory Lead Time | 16 Weeks | |
| Adjustability | Adjustable | |
| Dropout Voltage1-Max | 0.35 V | |
| Dropout Voltage1-Nom | 0.2 V | |
| JESD-30 Code | R-PDSO-G5 | |
| JESD-609 Code | e3 | |
| Length | 2.9 Mm | |
| Line Regulation-Max (%/V) | 0.05 | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 5 | |
| Operating Temperature TJ-Max | 125 °C | |
| Operating Temperature TJ-Min | -40 °C | |
| Output Current1-Max | 0.2 A | |
| Output Voltage1-Max | 1.218 V | |
| Output Voltage1-Min | 1.182 V | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | LSSOP | |
| Package Equivalence Code | TSOP5/6,.11,37 | |
| Package Shape | Rectangular | |
| Package Style | Small Outline, Low Profile, Shrink Pitch | |
| Packing Method | Tr | |
| Peak Reflow Temperature (Cel) | Not Specified | |
| Regulator Type | Adjustable Positive Single Output Ldo Regulator | |
| Seated Height-Max | 1.45 Mm | |
| Surface Mount | Yes | |
| Terminal Finish | Matte Tin (Sn) - Annealed | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.95 Mm | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | Not Specified | |
| Width | 1.6 Mm |
