MBRS140T3G Information
MBRS140T3G by onsemi is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for MBRS140T3G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
38K4488
|
Newark | Schottky Rectifier, Single, Do-214Aa, Repetitive Peak Reverse Voltage:40V, Average Forward Current:1A, Diode Configuration:Single, Diode Case Style:Do-214Aa (Smb), No. Of Pins:2Pins, Forward Voltage Max:600Mv, Product Range:- Rohs Compliant: Yes |Onsemi MBRS140T3G RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 98539 |
|
$0.0880 | Buy Now |
|
DISTI #
94W8544
|
Newark | Rectifier Diode, Single, 40 V, 1 A, Do-214Aa, 2, 600 Mv Rohs Compliant: Yes |Onsemi MBRS140T3G RoHS: Compliant Min Qty: 7500 Package Multiple: 1 Date Code: 0 Container: Tape & Reel | 2500 |
|
$0.0990 | Buy Now |
|
DISTI #
38K4488
|
Avnet Americas | - Product that comes on tape, but is not reeled (Alt: 38K4488) COO: China RoHS: Compliant Min Qty: 5 Package Multiple: 5 Container: Ammo Pack | 0 |
|
$0.1470 / $0.3700 | Buy Now |
|
DISTI #
94W8544
|
Avnet Americas | - Tape and Reel (Alt: 94W8544) RoHS: Compliant Min Qty: 7500 Package Multiple: 7500 Container: Tape & Reel | 0 |
|
$0.0980 | Buy Now |
|
|
Bristol Electronics | 6022 |
|
RFQ | ||
|
|
Bristol Electronics | 3133 |
|
RFQ | ||
|
|
Bristol Electronics | 1838 |
|
RFQ | ||
|
|
Bristol Electronics | Min Qty: 11 | 364 |
|
$0.1462 / $0.4875 | Buy Now |
|
DISTI #
MBRS140T3G
|
TME | Diode: Schottky rectifying, SMB, SMD, 40V, 1A, reel,tape Min Qty: 1 | 3591 |
|
$0.0700 / $0.3600 | Buy Now |
|
|
ComSIT USA | AVAILABLE EU | 18314 |
|
RFQ |
US Tariff Estimator: MBRS140T3G by onsemi
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
Part Details for MBRS140T3G
MBRS140T3G CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
MBRS140T3G Part Data Attributes
|
|
MBRS140T3G
onsemi
Buy Now
Datasheet
|
Compare Parts:
MBRS140T3G
onsemi
1.0 A, 40 V, Schottky Power Rectifier, Surface Mount, SMB, 2500-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Part Package Code | SMB | |
| Pin Count | 2 | |
| Manufacturer Package Code | 403A-03 | |
| Reach Compliance Code | Not Compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.80 | |
| Additional Feature | Free Wheeling Diode | |
| Application | General Purpose | |
| Configuration | Single | |
| Diode Element Material | Silicon | |
| Diode Type | Rectifier Diode | |
| Forward Voltage-Max (VF) | 0.6 V | |
| JEDEC-95 Code | DO-214AA | |
| JESD-30 Code | R-PDSO-C2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 40 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -65 °C | |
| Output Current-Max | 1 A | |
| Package Body Material | Plastic/Epoxy | |
| Package Shape | Rectangular | |
| Package Style | Small Outline | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 40 V | |
| Surface Mount | Yes | |
| Technology | Schottky | |
| Terminal Finish | Matte Tin (Sn) - Annealed | |
| Terminal Form | C Bend | |
| Terminal Position | Dual | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
Alternate Parts for MBRS140T3G
This table gives cross-reference parts and alternative options found for MBRS140T3G. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of MBRS140T3G, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| MBRA140TR | Vishay Intertechnologies | Check for Price | Rectifier Diode, Schottky, 1 Element, 1A, 40V V(RRM), Silicon, SMA, SMILILAR TO D-64, 2 PIN | MBRS140T3G vs MBRA140TR |
| NRVBA140T3G | onsemi | Check for Price | 1.0 A, 40 V, Schottky Power Rectifier, Surface Mount, SMA, 5000-REEL, Automotive Qualified | MBRS140T3G vs NRVBA140T3G |
| MBRS140 | Motorola Mobility LLC | Check for Price | SILICON, RECTIFIER DIODE, CASE 403A-03, SMB, 2 PIN | MBRS140T3G vs MBRS140 |
| RB160M-40TR | ROHM Semiconductor | Check for Price | Rectifier Diode, Schottky, 1 Phase, 1 Element, 1A, 40V V(RRM), Silicon | MBRS140T3G vs RB160M-40TR |
| MBRS140LT3 | onsemi | Check for Price | Schottky Power Rectifier, Surface Mount, 1.0 A, 40 V, SMB, 2500-REEL | MBRS140T3G vs MBRS140LT3 |
| SK14-7 | Diodes Incorporated | Check for Price | Rectifier Diode, Schottky, 1 Element, 1A, 40V V(RRM), Silicon, PLASTIC, SMB, 2 PIN | MBRS140T3G vs SK14-7 |
| MBRA140T3 | Motorola Mobility LLC | Check for Price | 1A, 40V, SILICON, SIGNAL DIODE, PLASTIC, CASE 403B-01, SMA, 2 PIN | MBRS140T3G vs MBRA140T3 |
| SBRS8140T3G | onsemi | Check for Price | 1.0 A, 40 V, Schottky Power Rectifier, Surface Mount, SMB, 2500-REEL, Automotive Qualified | MBRS140T3G vs SBRS8140T3G |
| MBRS140_NL | Fairchild Semiconductor Corporation | Check for Price | Rectifier Diode, Schottky, 1 Element, 1A, 40V V(RRM), Silicon, DO-214AA, SMB, 2 PIN | MBRS140T3G vs MBRS140_NL |
MBRS140T3G Frequently Asked Questions (FAQ)
-
The maximum operating temperature range for the MBRS140T3G is -55°C to 150°C.
-
To ensure proper soldering, use a soldering iron with a temperature of 250°C to 260°C, and apply a small amount of solder to the leads. Avoid applying excessive heat or pressure, which can damage the device.
-
The recommended storage condition for the MBRS140T3G is in a dry, cool place, away from direct sunlight and moisture. The storage temperature should be between -40°C to 30°C, and the humidity should be below 60%.
-
Yes, the MBRS140T3G is suitable for high-frequency switching applications due to its low forward voltage drop and fast switching times. However, ensure that the device is properly cooled and the maximum junction temperature is not exceeded.
-
To prevent ESD damage, handle the MBRS140T3G with an anti-static wrist strap or mat, and avoid touching the leads or body of the device. Use ESD-safe packaging and storage materials, and ensure that the device is properly grounded during handling.
