Resistors / Fixed Resistors / RMCF0201FT412R
Datasheets
RMCF0201FT412R by: SEI Stackpole Electronics Inc

Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201

Part Details for RMCF0201FT412R by SEI Stackpole Electronics Inc

Results Overview of RMCF0201FT412R by SEI Stackpole Electronics Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

RMCF0201FT412R Information

RMCF0201FT412R by SEI Stackpole Electronics Inc is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for RMCF0201FT412R

Part # Distributor Description Stock Price Buy
DISTI # 738-RMCF0201FT412RCT-ND
DigiKey RES 412 OHM 1% 1/20W 0201 Min Qty: 1 Lead time: 22 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) 13880
In Stock
  • 1 $0.1000
  • 10 $0.0270
  • 25 $0.0196
  • 50 $0.0156
  • 100 $0.0127
  • 250 $0.0099
  • 500 $0.0082
  • 1,000 $0.0070
  • 5,000 $0.0050
  • 10,000 $0.0044
  • 20,000 $0.0039
  • 30,000 $0.0037
  • 50,000 $0.0035
  • 70,000 $0.0033
  • 100,000 $0.0032
$0.0032 / $0.1000 Buy Now
DISTI # RMCF0201FT412R
Avnet Americas Res Thick Film 0201 412 Ohm 1% 1/20W ?200ppm/?C Molded SMD SMD Paper T/R - Tape and Reel (Alt: RMCF0201FT412R) COO: Taiwan (Province of China) RoHS: Compliant Min Qty: 10000 Package Multiple: 10000 Lead time: 18 Weeks, 0 Days Container: Tape & Reel 30000 Factory Stock
  • 10,000 $0.0023
  • 20,000 $0.0023
  • 40,000 $0.0022
  • 80,000 $0.0022
  • 160,000 $0.0022
$0.0022 / $0.0023 RFQ
DISTI # 708-RMCF0201FT412R
Mouser Electronics Thick Film Resistors - SMD RES, 0201, 412 ohm, 1%, 0.05W RoHS: Compliant 0
  • 10,000 $0.0030
$0.0030 Order Now
Onlinecomponents.com Thick Film Chip Resistor - 412 ohm ±1% - 0.05W - SMD 0201 - Tape&Reel COO: China RoHS: Compliant 0
  • 10,000 $0.0033
  • 30,000 $0.0027
  • 50,000 $0.0027
  • 100,000 $0.0026
  • 250,000 $0.0025
  • 500,000 $0.0024
  • 1,000,000 $0.0023
$0.0023 / $0.0033 Buy Now
DISTI # 27467862
Verical Res Thick Film 0201 412 Ohm 1% 0.05W(1/20W) ±200ppm/°C Pad SMD T/R Automotive AEC-Q200 RoHS: Exempt Min Qty: 10000 Package Multiple: 10000 Americas - 30000
  • 10,000 $0.0085
$0.0085 Buy Now
DISTI # 27467862
Verical Res Thick Film 0201 412 Ohm 1% 0.05W(1/20W) ±200ppm/°C Pad SMD T/R Automotive AEC-Q200 COO: Taiwan RoHS: Exempt Min Qty: 10000 Package Multiple: 10000 Americas - 30000
  • 10,000 $0.0085
$0.0085 Buy Now
NAC RESISTOR, 0201, 412 ohm, 1%, 0.05W - Thick film - General Purpose RoHS: Compliant Min Qty: 1 Package Multiple: 10000 30000
  • 10,000 $0.0050
  • 50,000 $0.0030
  • 250,000 $0.0024
$0.0024 / $0.0050 Buy Now
DISTI # 27467862
Verical Res Thick Film 0201 412 Ohm 1% 0.05W(1/20W) ±200ppm/°C Pad SMD T/R Automotive AEC-Q200 COO: Taiwan RoHS: Exempt Min Qty: 10000 Package Multiple: 10000 Americas - 30000
  • 10,000 $0.0085
$0.0085 Buy Now

US Tariff Estimator: RMCF0201FT412R by SEI Stackpole Electronics Inc

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

RMCF0201FT412R
SEI Stackpole Electronics Inc
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for RMCF0201FT412R

RMCF0201FT412R Part Data Attributes

Parametric Data
RMCF0201FT412R SEI Stackpole Electronics Inc
Buy Now Datasheet
Compare Parts:
RMCF0201FT412R SEI Stackpole Electronics Inc Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Package Description Chip
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8533.21.00.30
Factory Lead Time 17 Weeks
Construction Rectangular
JESD-609 Code e3
Mounting Feature Surface Mount
Number of Terminals 2
Operating Temperature-Max 155 °C
Operating Temperature-Min -55 °C
Package Height 0.23 Mm
Package Length 0.6 Mm
Package Shape Rectangular Package
Package Style Smt
Package Width 0.3 Mm
Packing Method Tr, Paper, 7 Inch
Rated Power Dissipation (P) 0.05 W
Rated Temperature 70 °C
Reference Standard Aec-Q200
Resistance 412 Ω
Resistor Type Fixed Resistor
Size Code 0201
Surface Mount Yes
Technology Metal Glaze/Thick Film
Temperature Coefficient 200 Ppm/°C
Terminal Finish Matte Tin (Sn) - With Nickel (Ni) Barrier
Terminal Shape Wraparound
Tolerance 1%
Working Voltage 25 V

Alternate Parts for RMCF0201FT412R

This table gives cross-reference parts and alternative options found for RMCF0201FT412R. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of RMCF0201FT412R, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
AS01FTF4120A Viking Tech Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP RMCF0201FT412R vs AS01FTF4120A
AS01FTF4120 Viking Tech Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201 RMCF0201FT412R vs AS01FTF4120
RMCS1/204121%A SEI Stackpole Electronics Inc Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201 RMCF0201FT412R vs RMCS1/204121%A
CR-01FA6--412R Viking Tech Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP RMCF0201FT412R vs CR-01FA6--412R
WCR-WCR0201LF-4120-F-P-LT TT Electronics Resistors Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201 RMCF0201FT412R vs WCR-WCR0201LF-4120-F-P-LT
AF0201FR-07412RL YAGEO Corporation Check for Price Fixed Resistor, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, RMCF0201FT412R vs AF0201FR-07412RL
CR0201F412RP10 Ever Ohms Technology Co Ltd Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201 RMCF0201FT412R vs CR0201F412RP10
AC0201FR-07412RL YAGEO Corporation Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP RMCF0201FT412R vs AC0201FR-07412RL
AF0201FR-13412RL YAGEO Corporation Check for Price Fixed Resistor, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, RMCF0201FT412R vs AF0201FR-13412RL
CR-01FAB--412R Viking Tech Corp Check for Price Fixed Resistor, Metal Glaze/thick Film, 0.05W, 412ohm, 25V, 1% +/-Tol, 200ppm/Cel, Surface Mount, 0201, CHIP RMCF0201FT412R vs CR-01FAB--412R
