Resistors / Fixed Resistors / TA203PA150RJE
Datasheets
TA203PA150RJE by: Ohmite Mfg Co

Fixed Resistor, Metal Glaze/thick Film, 3W, 150ohm, 500V, 5% +/-Tol, 50ppm/Cel, Through Hole Mount, 5010, RADIAL LEADED, ROHS COMPLIANT

Part Details for TA203PA150RJE by Ohmite Mfg Co

Results Overview of TA203PA150RJE by Ohmite Mfg Co

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Energy and Power Systems Transportation and Logistics Renewable Energy Automotive

TA203PA150RJE Information

TA203PA150RJE by Ohmite Mfg Co is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.

Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.

Price & Stock for TA203PA150RJE

Part # Distributor Description Stock Price Buy
DISTI # 64K6470
Newark Power Chip 3 Watts/ Tray Rohs Compliant: Yes |Ohmite TA203PA150RJE RoHS: Compliant Min Qty: 150 Package Multiple: 1 Date Code: 0 Container: Bulk 0
Buy Now
DISTI # TA203PA150RJE-ND
DigiKey RES 150 OHM 5% 3W POWERCHIP Min Qty: 150 Lead time: 12 Weeks Container: Bulk Temporarily Out of Stock
  • 150 $2.8169
$2.8169 Buy Now
DISTI # 588-TA203PA150RJE
Mouser Electronics Thick Film Resistors - Through Hole 3watt 150ohm 5% High Power RoHS: Compliant 0
  • 1 $6.3000
  • 10 $3.8100
  • 50 $3.0900
  • 100 $2.8200
  • 600 $2.6800
  • 1,050 $2.6300
  • 2,100 $2.5900
$2.5900 / $6.3000 Order Now
DISTI # 70587036
RS RESISTOR, THICK FILM, 150 OHMS, 3 W, 5%, SMT, PLANAR, HEAT SINK Min Qty: 150 Package Multiple: 1 Lead time: 22 Weeks, 0 Days Container: Bulk 0
  • 150 $3.4600
$3.4600 RFQ
Onlinecomponents.com Res Thick Film 150 Ohm 5% 3W ±50ppm/°C Glass RDL COO: Mexico RoHS: Compliant 0
  • 10 $3.4600
  • 50 $2.9000
  • 150 $2.6900
  • 300 $2.6100
  • 600 $2.4700
  • 1,050 $2.4300
  • 2,550 $2.3900
  • 5,100 $2.3400
$2.3400 / $3.4600 Buy Now
Master Electronics Res Thick Film 150 Ohm 5% 3W ±50ppm/°C Glass RDL COO: Mexico RoHS: Compliant 0
  • 10 $3.4600
  • 50 $2.9000
  • 150 $2.6900
  • 300 $2.6100
  • 600 $2.4700
  • 1,050 $2.4300
  • 2,550 $2.3900
  • 5,100 $2.3400
$2.3400 / $3.4600 Buy Now

US Tariff Estimator: TA203PA150RJE by Ohmite Mfg Co

Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.

TA203PA150RJE
Ohmite Mfg Co
Please specify a country of origin.
$
Please specify an import value in USD.
Estimator Results:
Tariff Percentage Tariff Calculation
Import Value
$.
Total Duty
$.
Total Estimate
$.
$.
Based on tariff data from

Part Details for TA203PA150RJE

TA203PA150RJE Part Data Attributes

Parametric Data
TA203PA150RJE Ohmite Mfg Co
Buy Now Datasheet
Compare Parts:
TA203PA150RJE Ohmite Mfg Co Fixed Resistor, Metal Glaze/thick Film, 3W, 150ohm, 500V, 5% +/-Tol, 50ppm/Cel, Through Hole Mount, 5010, RADIAL LEADED, ROHS COMPLIANT
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Package Description Radial,
Reach Compliance Code Compliant
ECCN Code EAR99
HTS Code 8533.21.00.90
Additional Feature Rated Ac Voltage (V): 1000
Construction Rectangular
JESD-609 Code e1
Lead Length 4.32 Mm
Lead Spacing 5.08 Mm
Mounting Feature Through Hole Mount
Number of Terminals 2
Operating Temperature-Max 180 °C
Operating Temperature-Min -55 °C
Package Height 15.24 Mm
Package Length 12.7 Mm
Package Shape Rectangular Package
Package Style Radial
Package Width 2.54 Mm
Rated Power Dissipation (P) 3 W
Rated Temperature 25 °C
Resistance 150 Ω
Resistor Type Fixed Resistor
Surface Mount No
Technology Metal Glaze/Thick Film
Temperature Coefficient 50 Ppm/°C
Terminal Finish Tin Silver Copper
Terminal Shape Flat
Tolerance 5%
Working Voltage 1500 V
