TPS92201AMDRLR Information
TPS92201AMDRLR by Texas Instruments is a Display Driver.
Display Drivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for TPS92201AMDRLR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-TPS92201AMDRLRDKR-ND
|
DigiKey | IC LED DVR REGULATOR 1.5A SOT563 Min Qty: 1 Container: Digi-Reel |
841 Digi-Reel® |
|
$0.1299 / $0.3000 | Buy Now |
|
DISTI #
296-TPS92201AMDRLRTR-ND
|
DigiKey | IC LED DVR REGULATOR 1.5A SOT563 Min Qty: 4000 Container: Tape & Reel |
841 Tape & Reel |
|
$0.1118 / $0.1208 | Buy Now |
|
DISTI #
296-TPS92201AMDRLRCT-ND
|
DigiKey | IC LED DVR REGULATOR 1.5A SOT563 Min Qty: 1 Container: Cut Tape |
841 Cut Tape |
|
$0.1299 / $0.3000 | Buy Now |
|
DISTI #
595-TPS92201AMDRLR
|
Mouser Electronics | LED Lighting Driver ICs 5V 1A or 1.5A high - efficiency synchron RoHS: Compliant | 0 |
|
$0.1200 / $0.3000 | Order Now |
