AD5270BRMZ-20-RL7 Information
AD5270BRMZ-20-RL7 by Analog Devices Inc is a Digital Potentiometer.
Digital Potentiometers are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for AD5270BRMZ-20-RL7
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
60AK6350
|
Newark | Digital Rheostat, Single, 1024 Step, End To End Resistance:20Kohm, No. Of Pots:Single, Control Interface:Serial, Spi, Track Taper:Linear, Resistance Tolerance:± 1%, Supply Voltage Min:2.7V, Supply Voltage Max:5.5V, No. Of Pins:10Pinsrohs Compliant: Yes |Analog Devices AD5270BRMZ-20-RL7 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 578 |
|
$2.7600 / $6.4700 | Buy Now |
|
DISTI #
AD5270BRMZ-20-RL7CT-ND
|
DigiKey | IC DGT RHE 20KOHM 1024TAP 10MSOP Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) |
2881 In Stock |
|
$2.8975 / $5.2300 | Buy Now |
|
DISTI #
584-AD5270BRMZ-20-R7
|
Mouser Electronics | Digital Potentiometer ICs 1024tap 5v 50tp, 1 R-tol MSOP SPI I.C. RoHS: Compliant | 12293 |
|
$2.6800 / $6.2800 | Buy Now |
|
DISTI #
V72:2272_06207250
|
Arrow Electronics | Digital Potentiometer 20kOhm 1024POS Non-Volatile Linear 10-Pin MSOP T/R COO: Taiwan RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2245 Container: Cut Strips | Americas - 7 |
|
$2.7570 | Buy Now |
|
|
Analog Devices Inc | 1024tap 5v 50tp, 1 R-tol MSOP Min Qty: 1 Package Multiple: 1000 | 2996 |
|
$2.6875 / $6.7500 | Buy Now |
|
DISTI #
66454963
|
Verical | Digital Potentiometer 20kOhm 1024POS Non-Volatile Linear 10-Pin MSOP T/R RoHS: Compliant Min Qty: 3 Package Multiple: 1 Date Code: 2245 | Americas - 7 |
|
$2.7570 | Buy Now |
|
DISTI #
V72:2272_06207250
|
Arrow Electronics | Digital Potentiometer 20kOhm 1024POS Non-Volatile Linear 10-Pin MSOP T/R COO: Taiwan RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2245 Container: Cut Strips | Americas - 7 |
|
$2.7570 | Buy Now |
|
DISTI #
66454963
|
Verical | Digital Potentiometer 20kOhm 1024POS Non-Volatile Linear 10-Pin MSOP T/R COO: Taiwan RoHS: Compliant Min Qty: 3 Package Multiple: 1 Date Code: 2245 | Americas - 7 |
|
$2.7570 | Buy Now |
|
DISTI #
V72:2272_06207250
|
Arrow Electronics | Digital Potentiometer 20kOhm 1024POS Non-Volatile Linear 10-Pin MSOP T/R COO: Taiwan RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks Date Code: 2245 Container: Cut Strips | Americas - 7 |
|
$2.7570 | Buy Now |
|
DISTI #
66454963
|
Verical | Digital Potentiometer 20kOhm 1024POS Non-Volatile Linear 10-Pin MSOP T/R COO: Taiwan RoHS: Compliant Min Qty: 3 Package Multiple: 1 Date Code: 2245 | Americas - 7 |
|
$2.7570 | Buy Now |
US Tariff Estimator: AD5270BRMZ-20-RL7 by Analog Devices Inc
Calculations from this tool are estimations only for imports into the United States. Please refer to the distributor or manufacturer and reference official US government sources and authorities to verify any final purchase costs.
Part Details for AD5270BRMZ-20-RL7
AD5270BRMZ-20-RL7 CAD Models
-
Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
AD5270BRMZ-20-RL7 Part Data Attributes
|
|
AD5270BRMZ-20-RL7
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
AD5270BRMZ-20-RL7
Analog Devices Inc
Digital Potentiometer, 1 Func, 20000ohm, 3-wire Serial Control Interface, 1024 Positions, PDSO10
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Part Package Code | TSSOP | |
| Pin Count | 10 | |
| Manufacturer Package Code | RM-10 | |
| Reach Compliance Code | Compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Bandwidth-Nom | 0.3 Khz | |
| Control Interface | 3-Wire Serial | |
| Converter Type | Digital Potentiometer | |
| JESD-30 Code | S-PDSO-G10 | |
| JESD-609 Code | e3 | |
| Length | 3 Mm | |
| Moisture Sensitivity Level | 1 | |
| Negative Supply Voltage-Nom | -2.5 V | |
| Number of Functions | 1 | |
| Number of Positions | 1024 | |
| Number of Terminals | 10 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | Plastic/Epoxy | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP10,.19,20 | |
| Package Shape | Square | |
| Package Style | Small Outline, Thin Profile, Shrink Pitch | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Resistance Law | Linear | |
| Resistance Tolerance-Max | 1% | |
| Resistor Terminal Voltage-Max | 2.75 V | |
| Resistor Terminal Voltage-Min | -2.5 V | |
| Seated Height-Max | 1.1 Mm | |
| Supply Voltage-Nom | 2.5 V | |
| Surface Mount | Yes | |
| Temperature Coefficient-Nom | 5 Ppm/°C | |
| Temperature Grade | Automotive | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | Gull Wing | |
| Terminal Pitch | 0.5 Mm | |
| Terminal Position | Dual | |
| Total Resistance-Nom | 20000 Ω | |
| Width | 3 Mm |
