NC7WZ17P6X by:

TinyLogic UHS Dual Buffer with Schmitt Trigger Inputs, 3000-REEL

Part Details for NC7WZ17P6X by onsemi

Overview of NC7WZ17P6X by onsemi

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Energy and Power Systems Renewable Energy Automotive

Price & Stock for NC7WZ17P6X

Part # Distributor Description Stock Price Buy
DISTI # 26AC2651
Newark Uhs 2 Buffer Schmitt Rohs Compliant: Yes |Onsemi NC7WZ17P6X Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel 0
  • 1 $0.0230
$0.0230 Buy Now
DISTI # 38C7625
Newark Schmitt Trigger Buffer, Sc-70-6, Logic Family/Base Number:-, Logic Device Type:Buffer, Schmitt Trigger, Logic Case Style:Sc-70, No. Of Pins:6Pins, Supply Voltage Min:1.65V, Supply Voltage Max:5.5V, Logic Ic Family:Nc7W, Msl:- Rohs Compliant: Yes |Onsemi NC7WZ17P6X Min Qty: 6000 Package Multiple: 1 Date Code: 0 Container: Cut Tape 0
  • 1 $0.0900
$0.0900 Buy Now
DISTI # NC7WZ17P6X
Avnet Americas Schmitt Trigger Buffer Dual Non-Inverting 6-Pin SC-88 T/R - Tape and Reel (Alt: NC7WZ17P6X) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 15 Weeks, 0 Days Container: Reel 219000
63000 Factory Stock
  • 3,000 $0.0229
  • 6,000 $0.0223
  • 12,000 $0.0217
  • 18,000 $0.0211
  • 24,000 $0.0205
  • 30,000 $0.0198
  • 300,000 $0.0192
$0.0192 / $0.0229 Buy Now
DISTI # NC7WZ17P6X
Avnet Americas Schmitt Trigger Buffer Dual Non-Inverting 6-Pin SC-88 T/R - Tape and Reel (Alt: NC7WZ17P6X) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 18 Weeks, 0 Days Container: Reel 63000 Factory Stock
  • 3,000 $0.0229
  • 6,000 $0.0223
  • 12,000 $0.0217
  • 18,000 $0.0211
  • 24,000 $0.0205
  • 30,000 $0.0198
  • 300,000 $0.0192
$0.0192 / $0.0229 Buy Now
Bristol Electronics   4371
RFQ
Bristol Electronics   2000
RFQ
Bristol Electronics   Min Qty: 27 105
  • 27 $0.1875
  • 81 $0.0938
$0.0938 / $0.1875 Buy Now
Bristol Electronics   70
RFQ
Ameya Holding Limited NC7WZ17 Series 5.5 V TinyLogic UHS Dual Buffer w/ Schmitt Trigger Inputs-SC-70-6 15861
RFQ
DISTI # SMC-NC7WZ17P6X
Sensible Micro Corporation Acvs (Dsc-Tor ) D3135-1993-01 RoHS: Compliant Min Qty: 25 Lead time: 0 Weeks, 1 Days Date Code: 2232 Container: Tape & Reel 9000
  • 100 $0.6800
  • 500 $0.6800
  • 1,000 $0.6800
$0.6800 RFQ
DISTI # SMC-NC7WZ17P6X
Sensible Micro Corporation OEM Excess 5-7 Days Leadtime, We are an AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days Date Code: 1932 Container: Tape & Reel 8531
RFQ
DISTI # SMC-NC7WZ17P6X
Sensible Micro Corporation Logic Circuit, Dual Buffer, CMOS, 6 Pin, Plastic, TSSOP RoHS: Compliant Min Qty: 25 Lead time: 0 Weeks, 1 Days Date Code: 1124 Container: Tape & Reel 25
  • 100 $0.8075
  • 500 $0.7863
  • 1,000 $0.7225
$0.7225 / $0.8075 RFQ
DISTI # NC7WZ17P6X
Avnet Asia Schmitt Trigger Buffer Dual Non-Inverting 6-Pin SC-88 T/R (Alt: NC7WZ17P6X) RoHS: Compliant Min Qty: 15000 Package Multiple: 3000 Lead time: 18 Weeks, 0 Days 0
  • 3,000 $0.2291
  • 6,000 $0.2261
  • 9,000 $0.2232
  • 15,000 $0.2204
  • 30,000 $0.2149
  • 75,000 $0.2097
  • 150,000 $0.2048
$0.2048 / $0.2291 Buy Now
DISTI # NC7WZ17P6X
Avnet Silica Schmitt Trigger Buffer Dual Non-Inverting 6-Pin SC-88 T/R (Alt: NC7WZ17P6X) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 19 Weeks, 0 Days Silica - 3000
Buy Now
DISTI # NC7WZ17P6X
EBV Elektronik Schmitt Trigger Buffer Dual Non-Inverting 6-Pin SC-88 T/R (Alt: NC7WZ17P6X) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 20 Weeks, 0 Days EBV - 267000
Buy Now
Flip Electronics Stock 156000
RFQ
MacroQuest Electronics ISO 9001: 2015, ISO 14001:2015, ISO 45001:2018 12103
  • 1 $0.1600
  • 10 $0.1300
  • 100 $0.1000
$0.1000 / $0.1600 Buy Now
New Advantage Corporation SC70-6/I�/TinyLogic UHS Dual Buffer with Schmitt Trigger Inputs RoHS: Compliant Min Qty: 1 Package Multiple: 3000 9000
  • 6,000 $0.0390
  • 9,000 $0.0361
$0.0361 / $0.0390 Buy Now
Sense Electronic Company Limited SC70-6 30800
RFQ

Part Details for NC7WZ17P6X

NC7WZ17P6X CAD Models

NC7WZ17P6X Part Data Attributes

NC7WZ17P6X onsemi
Buy Now Datasheet
Compare Parts:
NC7WZ17P6X onsemi TinyLogic UHS Dual Buffer with Schmitt Trigger Inputs, 3000-REEL
Pbfree Code Yes
Part Life Cycle Code Active
Ihs Manufacturer ONSEMI
Package Description SC-70, 6 PIN
Manufacturer Package Code 419B-02
Reach Compliance Code compliant
HTS Code 8542.39.00.01
Factory Lead Time 18 Weeks
Samacsys Manufacturer onsemi
Family LVC/LCX/Z
JESD-30 Code R-PDSO-G6
JESD-609 Code e3
Length 2 mm
Load Capacitance (CL) 50 pF
Logic IC Type BUFFER
Max I(ol) 0.032 A
Moisture Sensitivity Level 1
Number of Functions 2
Number of Inputs 1
Number of Terminals 6
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
Package Body Material PLASTIC/EPOXY
Package Code TSSOP
Package Equivalence Code TSSOP6,.08
Package Shape RECTANGULAR
Package Style SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Packing Method TR
Peak Reflow Temperature (Cel) 260
Power Supply Current-Max (ICC) 100 mA
Prop. Delay@Nom-Sup 13.1 ns
Propagation Delay (tpd) 15.8 ns
Qualification Status Not Qualified
Schmitt Trigger YES
Seated Height-Max 1.1 mm
Supply Voltage-Max (Vsup) 5.5 V
Supply Voltage-Min (Vsup) 1.65 V
Supply Voltage-Nom (Vsup) 1.8 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish Matte Tin (Sn) - annealed
Terminal Form GULL WING
Terminal Pitch 0.65 mm
Terminal Position DUAL
Time@Peak Reflow Temperature-Max (s) 30
Width 1.25 mm
