NUP2105LT1G Information
NUP2105LT1G by onsemi is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for NUP2105LT1G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
94T5894
|
Newark | Tvs Diode, Bidir, 44V, Sot-23, Product Range:-, Tvs Polarity:Bidirectional, Reverse Standoff Voltage:24V, Clamping Voltage Max:44V, Diode Case Style:Sot-23, No. Of Pins:3Pins, Minimum Breakdown Voltage:26.2V, Qualification:- Rohs Compliant: Yes |Onsemi NUP2105LT1G RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 30921 |
|
$0.1080 | Buy Now |
|
DISTI #
04X6657
|
Newark | Transient Voltage Suppressor, Tvs, Bidirectional, 24 V, Sot-23, 3, 26.2 V Rohs Compliant: Yes |Onsemi NUP2105LT1G RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 6000 |
|
$0.0720 / $0.0870 | Buy Now |
|
DISTI #
06R3477
|
Newark | Tvs Diode Array, 350W, 24V, Sot-23, Product Range:Nup21 Series, Tvs Polarity:Bidirectional, Reverse Standoff Voltage:24V, Clamping Voltage Max:44V, Diode Case Style:Sot-23, No. Of Pins:3Pins, Minimum Breakdown Voltage:26.2V Rohs Compliant: Yes |Onsemi NUP2105LT1G RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 1544 |
|
$0.1260 / $0.4000 | Buy Now |
|
DISTI #
NUP2105LT1G
|
Avnet Americas | TVS Diode, Bidirectional, 24 V, 44 V, SOT-23, 3 Pins - Tape and Reel (Alt: NUP2105LT1G) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 8 Weeks, 0 Days Container: Reel | 66000 |
|
$0.0710 / $0.0777 | Buy Now |
|
DISTI #
04X6657
|
Avnet Americas | TVS Diode, Bidirectional, 24 V, 44 V, SOT-23, 3 Pins - Tape and Reel (Alt: 04X6657) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 111 Weeks, 0 Days Container: Reel | 6000 Partner Stock |
|
$0.1010 / $0.1170 | Buy Now |
|
DISTI #
06R3477
|
Avnet Americas | TVS Diode, Bidirectional, 24 V, 44 V, SOT-23, 3 Pins - Product that comes on tape, but is not reeled (Alt: 06R3477) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 78 Weeks, 1 Days Container: Ammo Pack | 1544 Partner Stock |
|
$0.1580 / $0.2630 | Buy Now |
|
DISTI #
94T5894
|
Avnet Americas | TVS Diode, Bidirectional, 24 V, 44 V, SOT-23, 3 Pins - Tape and Reel (Alt: 94T5894) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 111 Weeks, 0 Days Container: Reel | 1084 Partner Stock |
|
$0.1440 / $0.3940 | Buy Now |
|
DISTI #
70341439
|
RS | Dual Bi-Directional TVS Diode 350W 3-Pin SOT-23 Min Qty: 20 Package Multiple: 1 Container: Bulk | 0 |
|
$0.3540 / $0.4170 | RFQ |
|
|
Bristol Electronics | 18088 |
|
RFQ | ||
|
|
Bristol Electronics | 633 |
|
RFQ |
Part Details for NUP2105LT1G
NUP2105LT1G CAD Models
NUP2105LT1G Part Data Attributes
|
|
NUP2105LT1G
onsemi
Buy Now
Datasheet
|
Compare Parts:
NUP2105LT1G
onsemi
27 V ESD Protection Diode - Dual Line CAN Bus Protector, SOT-23 (TO-236) 3 LEAD, 3000-REEL
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOT-23 (TO-236) 3 LEAD | |
| Package Description | TO-236, 3 PIN | |
| Pin Count | 3 | |
| Manufacturer Package Code | 318 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Factory Lead Time | 78 Weeks, 1 Day | |
| Samacsys Manufacturer | onsemi | |
| Additional Feature | LOW CAPACITANCE | |
| Breakdown Voltage-Max | 32 V | |
| Breakdown Voltage-Min | 26.2 V | |
| Breakdown Voltage-Nom | 29.1 V | |
| Case Connection | CATHODE | |
| Clamping Voltage-Max | 44 V | |
| Configuration | COMMON ANODE, 2 ELEMENTS | |
| Diode Element Material | SILICON | |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE | |
| JEDEC-95 Code | TO-236AB | |
| JESD-30 Code | R-PDSO-G3 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Peak Rev Power Dis-Max | 350 W | |
| Number of Elements | 2 | |
| Number of Terminals | 3 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | BIDIRECTIONAL | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 24 V | |
| Surface Mount | YES | |
| Technology | AVALANCHE | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
Alternate Parts for NUP2105LT1G
This table gives cross-reference parts and alternative options found for NUP2105LT1G. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of NUP2105LT1G, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| NUP2105LT3G | onsemi | Check for Price | 350W, BIDIRECTIONAL, 2 ELEMENT, SILICON, TVS DIODE, TO-236AB, LEAD FREE, CASE 318-08, TO-236, 3 PIN | NUP2105LT1G vs NUP2105LT3G |
