Transistors / Power Bipolar Transistors / TIP127
Datasheets
TIP127 by:

Low voltage PNP power Darlington transistor

Part Details for TIP127 by STMicroelectronics

Results Overview of TIP127 by STMicroelectronics

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

TIP127 Information

TIP127 by STMicroelectronics is a Power Bipolar Transistor.
Power Bipolar Transistors are under the broader part category of Transistors.

A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.

Price & Stock for TIP127

Part # Distributor Description Stock Price Buy
DISTI # 34X3387
Newark Darlington Transistor, To-220, Transistor Polarity:Pnp, Collector Emitter Voltage V(Br)Ceo:-100V, Transition Frequency Ft:-, Power Dissipation Pd:65W, Dc Collector Current:-5A, Dc Current Gain Hfe:1000Hfe, Transistor Case Rohs Compliant: Yes |Stmicroelectronics TIP127 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk 48
  • 1 $0.7090
  • 10 $0.4890
  • 100 $0.4400
  • 500 $0.3660
  • 1,000 $0.3260
  • 2,500 $0.3160
  • 10,000 $0.3060
$0.3060 / $0.7090 Buy Now
DISTI # TIP127
Avnet Americas Transistor Darlington PNP 100V 5A 3-Pin TO-220 Tube - Rail/Tube (Alt: TIP127) RoHS: Compliant Min Qty: 4000 Package Multiple: 1000 Lead time: 14 Weeks, 0 Days Container: Tube 0
  • 4,000 $0.1985
  • 6,000 $0.1975
  • 10,000 $0.1898
  • 20,000 $0.1863
  • 40,000 $0.1830
$0.1830 / $0.1985 Buy Now
STMicroelectronics Low voltage PNP power Darlington transistor RoHS: Compliant Min Qty: 1 9477
  • 1 $0.6200
  • 10 $0.4600
  • 100 $0.4100
  • 500 $0.3300
$0.3300 / $0.6200 Buy Now
Bristol Electronics   Min Qty: 4 1192
  • 4 $1.4625
  • 15 $0.9506
  • 54 $0.5484
  • 184 $0.4680
  • 397 $0.4095
  • 942 $0.3802
$0.3802 / $1.4625 Buy Now
Bristol Electronics   500
RFQ
Bristol Electronics   234
RFQ
Bristol Electronics   178
RFQ
DISTI # TIP127
TME Transistor: PNP, bipolar, Darlington, 100V, 5A, 65W, TO220AB Min Qty: 1 1670
  • 1 $0.6550
  • 10 $0.5650
  • 50 $0.4620
  • 100 $0.4200
  • 250 $0.3690
  • 500 $0.3350
  • 1,000 $0.3050
  • 10,000 $0.2720
$0.2720 / $0.6550 Buy Now
DISTI # TIP127
Avnet Silica Transistor Darlington PNP 100V 5A 3-Pin TO-220 Tube (Alt: TIP127) RoHS: Compliant Min Qty: 50 Package Multiple: 50 Lead time: 15 Weeks, 0 Days Silica - 33800
Buy Now
DISTI # TIP127
EBV Elektronik Transistor Darlington PNP 100V 5A 3-Pin TO-220 Tube (Alt: TIP127) RoHS: Compliant Min Qty: 50 Package Multiple: 50 Lead time: 15 Weeks, 0 Days EBV - 18700
Buy Now
LCSC 100V 10003V3A PNP 5A 2W TO-220 Darlington Transistors ROHS 403
  • 1 $0.3256
  • 10 $0.2593
  • 50 $0.2314
  • 100 $0.1945
  • 500 $0.1783
  • 1,200 $0.1694
$0.1694 / $0.3256 Buy Now
Win Source Electronics TRANS PNP DARL 100V 5A TO-220 26000
  • 190 $0.2663
  • 405 $0.2492
  • 625 $0.2406
  • 900 $0.2234
  • 1,165 $0.2148
  • 1,455 $0.2062
$0.2062 / $0.2663 Buy Now

Part Details for TIP127

TIP127 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

TIP127 Part Data Attributes

Parametric Data
TIP127 STMicroelectronics
Buy Now Datasheet
Compare Parts:
TIP127 STMicroelectronics Low voltage PNP power Darlington transistor
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer STMICROELECTRONICS
Part Package Code TO-220AB
Pin Count 3
Reach Compliance Code not_compliant
ECCN Code EAR99
HTS Code 8541.29.00.95
Factory Lead Time 14 Weeks
Samacsys Manufacturer STMicroelectronics
Collector Current-Max (IC) 5 A
Collector-Emitter Voltage-Max 100 V
Configuration DARLINGTON WITH BUILT-IN DIODE AND RESISTOR
DC Current Gain-Min (hFE) 1000
JEDEC-95 Code TO-220AB
JESD-30 Code R-PSFM-T3
JESD-609 Code e3
Number of Elements 1
Number of Terminals 3
Operating Temperature-Max 150 °C
Package Body Material PLASTIC/EPOXY
Package Shape RECTANGULAR
Package Style FLANGE MOUNT
Peak Reflow Temperature (Cel) NOT SPECIFIED
Polarity/Channel Type PNP
Power Dissipation Ambient-Max 65 W
Power Dissipation-Max (Abs) 65 W
Qualification Status Not Qualified
Surface Mount NO
Terminal Finish Matte Tin (Sn) - annealed
Terminal Form THROUGH-HOLE
Terminal Position SINGLE
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Transistor Application SWITCHING
Transistor Element Material SILICON
VCEsat-Max 4 V

Alternate Parts for TIP127
